F245580 | AIR SPRING 9875, 1R12-432 | Replace FAS-0729

F245580 | AIR SPRING 9875, 1R12-432 | Replace FAS-0729

SKU: SKU:F245580

Inventory: More than 50 in Stock

Shipping: Calculated at Checkout

Regular price $ 181.41 USD
Regular price Sale price $ 181.41 USD
Sale Sold out
Shipping calculated at checkout.

Shipping Policy

In order to send your purchase, our company may use different freight companies like USPS, UPS and some 3erd Carrier Services for Oversize orders, this will not affect the final price of your order. We will send you all the information in due time.

For Free Shipping and Freight/Oversize Shipments they are some special term you may check at our Terms & Conditions page.

Return Policy

If for any reason you need to return a purchased item, we have a 30-day return policy, which means you have 30 days after receiving your item to request a return.

To be eligible for a return, your item must meet the conditions established in our Terms & Conditions.

To start a return, use our Contact Form

View full details


Product Data Sheet


The Fortpro Air Spring F245580 is an air suspension component that elevates performance and comfort in automotive vehicles. Precision manufactured using premium materials and advanced technology, this air spring ensures exceptional durability and strength. With its strong cylindrical design, the F245580 features a reinforced synthetic rubber membrane that offers exceptional load capacity and superior fatigue resistance.


  • Brand: Fortpro
  • Part Type: Air Spring / Air Spring Bag / Suspension Air Spring
  • Vehicle Type: Semi-Trucks, Heavy-Duty Trucks
  • Part OEM: W013581191, W01-358-1191
  • Position: Primary Truck & Trailer Axle
  • Air Spring Style: 1T Reversible Sleeve
  • Piston Type: Composite
  • Bead Plate Diameter Bottom: 10.00"
  • Bead Plate Diameter Top: 9.00"
  • Collapsed Height: 5.96"
  • Max. Height: 23.79"
  • Part Diameter: 10.00"
  • Piston Height: 4.65"
  • Stud Configuration-Bottom: 1
  • Stud Configuration - Top: 2
  • Weight:: 12.20 lbs
  • Application: Bead plate Bracket (Single Hole) 70-3582-6063; Navistar 3541731C1; Goodyear 1R12-432
  • VMRS: 016-008-000
  • Notes: W01-358-1191 Replaces W01-358-9875


  • Automann: 566CT73746, AB1DF23IP1067
  • Contitech: 910S18P1067(BK)
  • Dayton Parts Batco: 1R121077, 1R12432, 3521191
  • Firestone: W013581191, W01-358-1191


Dimension Not Available.
